Telescopic Spreader Beams
Description
Queensland Rigging Hire offer telescopic spreader beams for hire and rental. Manufactured by Maxirig, the beams range in size from 6 to 80 tonnes, with varying spans of 2 to 6 metres. Our spreader beams are supplied with test certificates and maintained to manufacturer standards.
Queensland Rigging Hire also hire a range of Modular Spreader Beams and End Cap Spreader Beams for hire.
| WLL | SPAN | TARE | SPECIFICATIONS | SHACKLES | DOWNLOAD |
| 3t | 1.8 - 3.0m | 40kg | 1.8m - 3.0m in 100mm increments | 3.2t upper & lower | Download |
| 6t | 2.0 - 3.0m | 50kg | 2.0m - 3.0m in 200mm increments | 4.7t upper & lower | Download |
| 6t | 3.0-5.0m | 105kg | 3.0m - 5.0m in 250mm increments | 4.7t upper & lower | |
| 10t | 4.0 - 6.0m | 160kg | 4.0m - 6.0m in 250mm increments | 8.5t upper & 6.5t lower | Download |
| 10t | 7.0m - 12.0m | 375kg | 7.0 - 12.0m in 250mm increments | 8.5t upper & 6.5t lower | |
| 20t | 2.65 m - 4.0m | 150kg | 2.65m - 4.0m in 500mm increments | 17t upper & 12t lower | Download |
| 20t | 4.0 m - 6.0m | 215kg | 4.0m - 6.0m in 500mm increments | 17t upper & 12t lower | Download |
| 30t | 2.8m - 4.0m | 200kg | 2.8m - 4.0m in 100mm increments | 25t upper & 17t lower | Download |
| 30t | 4.0m – 6.0m | 260kg | 4.0m – 6.0m in 250mm increments | 25t upper & 17t lower | Download |
| 30t | 6.0m - 9.0m | 475kg | 6.0m - 9.0m in 250mm increments | 25t upper & lower | Download |
| 30t | 6.4 - 9.1m | 850kg | 6.1m - 9.1m in 250mm increments | 25t upper & lower | |
| 50t | 2.8m - 4.0m | 260kg | 2.8m - 4.0m in 400mm increments | 35t upper & 25t lower | Download |
| 50t | 4.0m - 6.0m | 360kg | 4.0m - 6.0m in 500mm increments | 35t upper & 25t lower | Download |
| 50t | 7.5 - 12.0m | 870kg | 7.5 - 12.0m in 250mm increments | 35t upper & lower | |
| 80t | 4.0m - 6.0m | 605kg | 4.0m - 6.0m in 500mm increments | 55t upper & 55t lower | Download |
Note: The information on this page is indicative only. Please consult our team before undertaking any operations with this device.
